AM Step 1 Objectives
- Prevent Forced Deterioration
- Restore Latent Defects in Equipment
- Identify Source of Contaminants
Understand machine Structures & Function
Activity – Go to the Genba (Actual Place!):
1. Deep Cleaning
2. Discover Potential Problems Fuguai
4. Tentative Action for SOC
5. Routine Cleaning Stds
AM Step 1 Flow (Don’t forget SAFETY FIRST!):
Zero Energy State (ZES) or Lock Out & Tag Out (LOTO)
Follow proper LOTO OPL’s to effectively isolate all energy sources on equipment to be worked on
- PPE: Wear proper Personal Protective Equipment
- SOE: Know your Sources of Energy
- LOTO: Lock your equipment out properly
5S Activities – SEIRI & SEITON (Sort out and Set)
- Perform the SORT activity of 5S
- Create the “Red Tag Zone” for those items you do not need
AM Step 1 – STORE (SET)
- Perform the STORE (SET) activity of 5S
- Store EVERYDAY items in a convenient location — where it is needed
- Store ONCE IN A WHILE items out of the way, but in a known, logical location
- Use pictures, labels, colours, tape, paint, OPLs, etc. to standardize the STORE location
AM Step 1- Initial Clean Cleaning With Meaning!
- Clean to Inspect (Look for Fuguai)
- Inspect to Detect (ID SOC & HTA)
- Detect to Correct
- Correct to Perfect
Perfection is Satisfaction!
Problems caused by insufficient cleaning
What is “Fuguai“? Fuguai = Problem or Abnormality
- functional defects
- difficult to access / observe
- hard to tend / serve
Where Do You Find “Fuguai“?
- nuts and bolts, screws
- chains, links, pulleys, buffers
- springs, spanners, cylinders
- piping and related parts
- valves, gaskets,controls, filters
- couplings, bearings, shaft
- switches, sensors
- cabling and related parts
- indicators, monitors, screens
- guards, doors, windows
- emergency switches, safety devices…
- main equip.
- operate system
- moving and turning parts
- transport systems
- hydraulic system
- compressed air system
- storage system
- cool/heating system
- instrumentation and controls
What Malfunctions are “Fuguai“?
- Wear, Play, Slackness
- Leakage, Spills
- Dust, Dirt, Contamination, Corrosion
- Deformation, Surface Damage
- Cracking, Overheating
- Vibration, Noise
- Safety Hazards
How to Discover “Fuguai“?
Use your 5 senses:
- SEE –> use your eyes to observe
- HEAR –> listen and try to hear the unusual noises
- SMELL –> try to discover strange smells
- TOUCH –> try to feel heat, vibrations
- TASTE –> not normally recommended, but can be done from time to time
Use your brain: think before you make a judgement
How to find “Fuguai” During Initial Clean?
- 1st step: OBSERVATION
Before doing anything, first observe the machine as a whole to find all visible defects
- 2nd step: CLEANING (1st phase)
Clean the machine thoroughly such that all hidden defects will be uncovered
- 3rd step: DISASSEMBLING PARTLY
disassemble the main components of the machine and if possible, find the visible defects as done with step 1
- 4th step: CLEANING (2nd phase)
Clean parts and components that can be accessed after disassembly
- 5th step : ASSEMBLING
- Before you wipe and clean anything…
- TAKE A GOOD LOOK AROUND!
- You don’t want to miss potential FUGUAI !!! (Example loose fastener on the floor)
CLEANING (1st Phase)
- Next, perform a deep clean on the main body of the equipment, touching every component of the machine to discover hidden FUGUAI. (Example found worn chain guide)
- Now that the main body is clean, Start disassembling the sub components of the equipment to discover even more hidden Fuguai.
- Most of the hidden components of a machine that have never been through AM Step 1 will look like on the picture with dirty machine components.
CLEANING (2nd Phase) & REASSEMBLE
- Once all Fuguai have been identified in the sub components, clean the area and reassemble when complete.
As mentioned earlier, you will find many Fuguai during the deep cleaning of the equipment! But what is to be done to keep track of all of them?
FUGUAI TAGS, OF COURSE or simply F-Tags
Collect Evidence (Genbutsu)…
- Broken Parts
- Worn Parts
- Debris, Contaminants…
Save these parts and contaminants as evidences and treasures of your hard work. (You’ll use them later)
It won’t do much good to just put F-tags on the machine and collect our Fuguai. We must keep track of the progress.
An F-Tag is also a visual work order
“Four Lists” are to be used to track (Simple Excel Spreadsheets can be created):
- Abnormality List
- F – Tag Tally Sheet
- SOC (Sources of Contamination) List
- HTA (Hard-to-Access) List
Also it’s a good idea to create F-tag tracking center (board)
Tentative Cleaning Standard
Tentative Countermeasures are extremely important!!!
Not only do they help reduce cleaning time the second time around, they help reduce forced deterioration.
- Were the “Fixes” effective?
- In this step, we may need to “Re-Tag” to ensure the abnormality has been successfully eliminated
- Think of this as the “Verify” step
AM STEP 1 CHECKLIST
Auditing Process: Line Team performs self audit. If they pass with a score of 80% or more, then the management team performs an audit. If the line passes with a score of 80% or more, the line/equipment moves to the next AM Step.
